Configuration:

Flat Panel Detector
- Detector technology: Wireless a -Si Flat Panel Detector
- Scintillator material: CsI
- Images size: 350mm x 430mm
- Static pixel matrix: 2500 x 3052pixels
- Effective pixels: 7.60million
- Pixel size: 140μm
- Spatial resolution: 3.5lp/mm
- Output grayscale: 16bit
- Acquisition time: ≤7s

High Frequency Generator
- Nominal output power: 32kW
- Max output power: 40kW
- Frequency: 50kHz/60kHz ± 1Hz
- kV range: 40~150kV, 1kV step
- mA range: 50 -400mA
- mAs range: 1~630mAs
- Power requirement: 220V

X-ray tube
- Focus: 0.6/1.2mm
- Voltage: 150kV
- Anode type: Rotating
- Anode heat capacity: 300kHU
- Anode angle: 12°

Mobile Stand
- The Vertical Movement Range of X -ray Tube Center along the Column: 580~1800mm
- The Telescopic Movement Range of X -ray Tube Center along the Column Side: 720~1220mm
- Stand Column Horizontal Rotation Range: ±315°
- Collimator Rotation Range along the vertical axis: ±90°
- Mobile Stand Size: 1230 × 580 × 1820 mm

Collimator
- Control: Manual
- Filter: 1.2mm Al
- Light: LED lamp

DX Ray Diagnostic Workstation
- Display size: 19inch
- Pixel matrix: 1280 x 1024pixels
- Patient Management: manual registration, WORKLIST automatic query.
- Image Acquisition: automatic window adjustment, automatic cropping, automatic transmission.
- Image Processing: image correction, image flipping.
- Image Observation: window width window level adjustment, image flipping, image rotation, image scaling, and restoration.
- Medical Record Report : automatic loading of patient information
- Film Printing: support DICOM3.0 standard laser camera printing.
- DICOM Transfer: send images to any PACS and workstation that complies with the DICOM 3.0 standard.

Other features
Dose control mode
- APR (Anatomically Programmed Radiography) mode
- Manually setting the exposure mode
Mobility performance
- Electrically assisted drive and has brake equipment
- Support switch to manual mode without power
- Slope assist system, maximum movement slope: ≤8 °
Collision resistance
- Collimator protector against human collision
- Braking function for moving object collision
- Slope assist system, maximum movement slope: ≤8 °
Interactive system
- Time -lapse exposure function
- Remote visual observation system and intercom system
Power management system
- Battery power display device
- Independent control system for power assist and high frequency generator exposure output
- Quick charging mode
- Power intelligent management system: computer sleep, high frequency generator sleep mode
- Intelligent power switching function: support exposure during charging
