CHARACTERISTICS:
1.With safety valve, release valve and gauge, when the steam pressure go over 0.165Mpa, the release valve should exhaust the pressure to ensure the safety, there is reading on the gauge face for both Mpa and temperature for check the data.
2.The product adopts immersion electro thermal tube to heat.
3.The container and drum adopted stainless steel 0Gr18Ni9Ti, anti-acid, anti-alkali and anti-rust
TECHNICAL DATA:
| Model Technical Data |
YX-280 |
YX-280(Deepened) |
| sterilizing volume |
18L(φ280×260 mm) |
24L(φ280×390 mm) |
| working pressure |
0.14 -0.16 MPa |
| working temperature: |
126°C |
| temperature adjust range |
105-126°C |
| Max. safety pressure |
0.165Mpa |
| heat average |
<±1°C |
| power / consumption |
AC220V.50Hz / 2KW |
| dimension |
410×410×520 mm |
410×410×630 mm |
| N / G. W |
16 / 18KG |
17 / 19 KG |
|
|
