General
Monitoring Parameters:SpO2, PR, Pulse strength
Signal sockets: SpO2 socket
Display screen
Type:Red LED
Display area:56mm×36mm
Size:120mm×63mm×32mm
Weight:125g (not include sensor and battery)
Features
Audio and visual alarm:
The speaker sounds the alarm and the parameter’s measurement flashes on the screen.
Prompting: Indicator of battery capacity.
Power saving: The monitor will automatic shut down when no monitoring for 3 minutes.
Electrical specifications
Working Voltage:D.C. 2.8V - D.C. 5.4V.
Battery
Type:Three common 1.5V AA alkaline or rechargeable batteries
Run Time:7-hour continuous operation with a new battery
Parameter Specifications
SpO2
Patient:Adult, pediatric, infant, neonate, animal
Range:35 - 99%
Resolution:1 %
Accuracy:±2 % (70% - 99%), unspecified (0% - 69%)
PR
Range:30~250bpm
Resolution:1bpm
Accuracy:±2bpm
|
|
