Main Features:

10 inch VGA monitor
Four probes acceptable: convex, linear, transvaginal and endorectal
Wide applications: Abdominal, OB/GYN, Urology, Cardiology, Small parts examination etc.
3 step multi-frequency
Measurement: Distance, circumference, area,　fetal weight,fetal heart rate
OB measurments: BPD, GS, CRL, FL, AD, HC, AC
15 body marks
Gestation Age: 4th-43rd week
4-step zooming: x1.0, x1.2, x1.5, x2.0 with scroll-up depth control
2-probe connectors

Technical Specification :

Scanning mode: Convex/Linear
Display modes: B,B+B,B+M,M
Scanning depth: 220mm
Gray scales: 256
Cine-loop: 186 frames
Image permanent storage: 20 frames
Image magnification: ×1.0,×1.2,×1.5,×2.0
Image conversion: up/down, left/right, black/white
Zoom: 2 times both in real-time and frozen
Frame correlation: Three levels to adjust (B、B+B mode)
Electronic focuses: 4-sector dynamic
Depth scroll up in B and B+B modes
Resolution Lateral:≤2mm, axial≤1mm
Body marks: 15
Measurement: Distance, circumference ,area, heart rate, EDD
Comment : date , name , sex, age , hospital , annotation
Coded-colors : 7
Video output: PAL-D , ACE , Noninterlace , VGA
Monitor: 10 inch VGA
Power Supply: 100V~130V/220V~240V, 50/60Hz
Weight: 11.5 Kg(including probe)
Dimensions(mm): 353Χ315Χ253
Packing dimensions(mm):430×390×410

Standard configuration:

C1-2/60R/3.5MHz Multi-freq Convex Probe

Options:

1). L4-1/7.5 MHz Multi-freq Linear Probe
2). EC3-1/13R/6.5 Multi-freq MHz Convex Probe
3). EL1-1/7.5 MHz Multi-freq Rectal Linear Probe
