Features:
- Fully automatic
- Easy Windows operature system, large LCD display
- Washes flat, round and V-bottom strips and plates
- 12-way or 8 way manifold, automatic and manual positioning
- Large memory to store upto 50 wash protocols
- Automatic monitoring for vacuum and pressure, automatic rinse cycle
- Automatic check for plate and strip
- Washing pressure, volume and time adjustable
- Liquid level sensor and alart feature
- Liquid level sensor and alart feature
- No special airtight bottle required for wash bottle
- Easy maintenance design
Technical Specifications:
Plate Mode |
96- or 48- well plate or strip |
Dispense Precision |
CV < 2% |
Residual Volume |
<1µL |
Washing Volume |
50-3000L for 8-way manifold |
50-2000L for 12 way manifold |
Washing Cycle |
Maximum 99 cycles |
Strip Washing |
1 to 12 channels adjustable |
Soaking Time |
0-24 hours |
Display |
5" LCD |
Bottle Capacity |
2 liters each |
Memory |
50 washing protocols |
Interface |
RT-232 serial port |
Net Weight |
8Kg |
Dimensions |
390mm x 340mm x 180mm |
Power Supply |
AC 220V±10%, 50-60Hz, 110V on request |
|
|
