| Features:
Easy Keypad operation with LCD display
Wavelengths from 330-800nm, 5 standard filters, 3 more filters optional
Reagent-open system supports flowcell and cuvette mode, close system on request
Analytical modes include kinetic, two point, bichromatic end point with or without reagent blank or sample blank, linear or non-linear calibration curves
Memory for 60 programs and 2200 test results
Excellent QC function, 2 controls per test
Internal thermal-sensitive printer
Compact design enables USER-DIY maintenance
Standard English or other languages software available on request
Main Specifications:
Absorbance Range |
-0.500-3.000 Abs |
Resolution |
0.001Abs(displayed), 0.0001 Abs (Calculated) |
Light Source |
Halogen Lamp |
Wavelengths |
340, 405, 500, 546, 620nm, 3 more filters optional |
Wavelength Accuracy |
1nm |
Band Width |
<8nm |
Cross Contamination Rate |
<1% |
Interface |
RS-232 serial cable |
Flow Cell |
Metal quartz flow cell |
Temperature Control |
25°C , 30°C , 37°C , and ambient temperature |
Display |
LCD display |
Output |
Internal printer or external printer (optional) |
Power Supply |
AC 100V-240V, 50-60Hz |
Net Weight |
7Kg |
Dimensions: (LxWxH)(mm) |
360x318x160 |
|
|
