Features:
- Brushless motor drive
- Large screen backlight LCD shows
- Stainless steel chamber
- Speed/running time/Accel / Decel adjustable
- With RCF/RPM toggle key to check the RCF
- Error code ,speed Accel/ Decel rates 10 programs
- Over speed alarm, finished alarm
- With electronic door lock and safety switch
Specifications:
| Model |
TDL-4A Plus |
| MAX RPM |
4000 RPM |
| Max RCF |
2325xg |
| Timer |
0-99min |
| Rotor capacity |
Angle 20mlx24(Standard) |
| Voltage |
110V 60Hz /220V 50Hz |
| Dimension(mm) |
330x410x330mm |
| Weight |
15kg |
Rotor No. |
Rotor capacity |
Max RCF |
A042024 |
20mlx24 |
2325xg |
A042012 |
20mlx12 |
2325xg |
A042016 |
20mlx16 |
2325xg |
A045006 |
50mlx6 |
2800xg |
|
|
