CHARACTERISTICS:
1.Whole body inner and outer by stainless steel
2.Hand wheel type of quick-open door structure
3.Pressure safety lock
4.Indicator light indicates working state
5.Over temperature&over pressure auto-protection
6.Double scale indication pressure gauge
7.Self-inflating type seal
8.Safe protection of water lacking
9.Automatically shut off with beep reminding after sterilization
10.Easy to operate，safe and reliable
11.With two stainless steel sterilizing baskets
TECHNICAL DATA :
| Model technical data |
LS-B35L-I |
LS-B50L-I |
LS-B75L-I |
LS-B100L-I |
| Valid volume |
35L(φ318×450)mm |
50L(φ340×550)mm |
75L(φ400×600)mm |
100L(φ440×650)mm |
| working pressure |
0.22MPa |
0.14MPa |
| Working temperature |
134°C |
126°C |
| Max working pressure |
0.23 Mpa |
0.165MPa |
| Heat average |
<±1°C |
| Timer |
0-60min |
| Adjustment of temperature |
105-134°C |
105-126°C |
| Power |
2.5Kw/AC220V.50Hz |
3Kw /AC220V.50Hz |
1.obtion 4.5KW /AC220V.50Hz 2.obtion 6.0KW /AC380V.50Hz |
| Overall dimension |
450×450×1010(mm) |
510×470×1130(mm) |
540×560×1100(mm) |
540×560×1250(mm) |
| Transport dimension |
510×480×1100(mm) |
590×580×1230(mm) |
650×630×1300(mm) |
630×650×1400(mm) |
| N/G |
50Kg/ 62Kg |
86Kg/ 68Kg |
82Kg/105Kg |
95 Kg/105Kg |
Note: With timing, temperature adjuster, water cut |
