Features
--
Large LCD screen (128x64 Dots
--
Can display and save 50 groups of data, 3 groups per screen
--
Data can be restored after a sudden power cut
--
Auto setting wavelength
--
Tungsten lamp & deuterium lamp can be turned on/off individually to extend lifetime
--
Automatical WL. calibration and dark current getting
--
Optional software UV-Professional can expand the applications to Kinetics and Quantitatives.
Specifications:
| Model |
V-5100 |
| Optical System |
Single beam, Grating 1200 lines/mm |
| Wavelength Range |
325-1000nm |
| Bandwidth |
4nm |
| Wavelength Accuracy |
±1nm |
| Wavelength Repeatability |
0.5nm |
| Wavelength Setting |
Auto |
| Photometric Accuracy |
±0.5%T |
| Photometric Repeatability |
0.3%T |
| Photometric Range |
-0.3-3A,0-200%T |
| Stray Light |
≤0.3%T |
| Stability |
± 0.002A/h @ 500nm |
| Display |
128*64 Dots LCD |
| Detector |
Silicon Photodiode |
| Standard Cell Holder |
4-position 10mm cell changer |
| Light Source |
Tungsten Lamp |
| Output |
USB Port & Parallel Port(Printer) |
| Power Requirements |
AC 85~250V |
| Dimension |
420*280*180mm |
| Weight |
10kg |
|
|
