XSZ-107BN Binocular Microscope

Model

XSZ-107BN

Achromatic Objectives

4X, 10X, 40X (S ), 100X ( S, Oil )

Eyepiece

Wide Field Eyepiece , WF10X, (WF16X for choice )

Eyepiece head

Sliding Binocular Head Inclined at 45°

Stage

Double Layer Mechanical Stage Size 140X140mm,Moving Range 75X45mm

Focusing

Coaxial Coarse and Fine Adjustment,Focusing Range 30mm, Focusing Interval 0.002mm

Condenser

Abbe NA=1.25 with lris Diaphragm&Filter

IIIumination

Halogen Lamp 220V/6V20W or 110V/6v20W

Option

Quintuple LED light
